Stilo Communications Kits
Discovery Parts does not recommend installing these kits without proper training and tools. Call us at (888) 748-7223 and we'll make arrangements for you to send your helmet to us for professional installation and/or retrofitting.
PLEASE NOTE: We will not warranty any Stilo communications kit that has not been professionally installed by our team of experts.
Stilo AE0210 Details:
- Manufacturer: Stilo
- Manufacturer part number: AE0210
- Microphone: Yes, Gentex button shaped microphone that fits in chin bar of all Stilo Helmets
- Speakers: Yes, mounted in nose reducing padded Stilo Ear Cups
- Wiring protocol: Female IMSA (4C)
The Stilo AE0210 is easily the #1 Stilo electronics wiring kit. Fitting all Stilo ST5 GT helmets that have side ports, SA2020, FIA 8859, FIA 8860-2010 and FIA 8860-2018. The round, button microphone is placed into the factory installed hole in the chinbar padding and ear cups are placed into the recesses on each side of the helmet.
Stilo AE0214 Details:
- Manufacturer: Stilo
- Manufacturer part number: AE0214
- Audio in: Earbud 3.5mm female jack
- Microphone: Gentex button shaped microphone that fits in chin bar of all Stilo Helmets
Who would want the Stilo AE0214? Anyone with a Stilo helmet with custom earbuds that does not want the ear-cups installed. If you find ear cups uncomfortable and use ear buds, then the Stilo AE0214 electronics kit is for you.
Audio In: This Stilo EarBud Rally electronics kit uses the Stilo 3.5mm female earbud jack. All audio will be played into your ear buds.
Microphone: Your Stilo helmet has a female recess in the front chin bar to place a microphone. The Stilo EarBud Electronics gives you a microphone that fits into the recessed area of your Stilo chin bar.
Stilo AE0320 Details:
-
Manufacturer: Stilo
- Manufacturer part number: AE0320
- Audio in: Earcup and Earbud, both work at the same time
- Audio out: Gentex flex boom microphone
- Stilo description: Gen Boom, Speakers, Earbuds 3.5mm
What racers prefer the Stilo AE0320? Anyone with an extremely loud race engine. Some formula cars with the engine close to the driver or a ultra high compression race V8. If your car is very loud, or you went to too many Who concerts when you were younger, this is a great communication upgrade.
Audio In: This Stilo Dual Rally electronics kit uses the proven Stilo powered ear cup audio electronics for each ear, but also lets you use your earbuds in addition. The audio will be played into both the ear cups and your earbuds at the same time.
Microphone: Your Stilo helmet has a female recess in the cheek pad backing and front chin bar to place a noise canceling microphone. The Stilo Dual Rally & Ear Bud Electronics gives you a Gentex noise canceling microphone on a flex boom. You can place the microphone barely touching your upper lip and save your crew chiefs ears.
Stilo AE0216 Details:
- Manufacturer: Stilo
- Manufacturer part number: AE0216
- Microphone: Gentex boom-mounted noise-canceling mic
- Speakers: Mounted in noise reducing padded Stilo Ear Cups
The Stilo AE0216 wiring kit takes the proven ear cups from the AE0210 kit, but replaces the round button microphone with a boom microphone. The boom style microphone allows the driver to place the microphone barely touching their upper lip. This reduces ambient noise transmission through your radio system. This is a great choice for loud cars or anything with a straight cut gearbox.
Stilo AE0321 Details:
- Manufacturer: Stilo
- Manufacturer part number: AE0321
- Wiring protocol: IMSA (4C)
- Audio in: Earcup
- Audio out: Gendex flex boom microphone
- Stilo description: 4 Conductor, Gentex Boom Mic, Earcup Speakers and Earbud 3.5mm Jack
Who would want the Stilo AE0321? First you would have a Stilo Formula or Naked Helmet (no side ports), have a race car wired with IMSA communications and want the Stilo noise reduction ear cup communication. Some formula cars with the engine close to the driver or a ultra high compression race V8. If your car is very loud, or you went to too many Who concerts when you were younger, this is a great communication upgrade.
Helmet connection: This Stilo cable uses an IMSA (4C) male plug attached to a coil cord to ensure there are no accidental disconnects.
Audio In: This Stilo Ear Cup Electronics with Flex Mic and IMSA Coil Cord uses the proven Stilo earcup audio electronics to keep the race car out and the crew member in your ear. There is also a 3.5mm female jack for earbuds. The receiving audio will work through the ear cups or earbuds or both together. This is a proven race worth set-up.
Microphone: Your Stilo helmet has a female recess in the front chin bar to to place a noise cancelling microphone, but the 0231 kit uses a Gentex noise cancelling microphone on the end of a flex-boom so you can place the microphone so it is barely touching you upper lip. This is popular in hi-speed formula cars, and extreme environments like Baja 1000, power boats, V8 SuperCars etc.
Stilo AE0322 Details:
- Manufacturer: Stilo
- Manufacturer part number: AE0322
- Wiring protocol: NASCAR (3C)
- Audio in: Earcup
- Audio out: Gendex flex boom microphone
- Stilo description: 3 Conductor, Gentex Boom Mic, Earcup Speakers and Earbud 3.5mm Jack
Who would want the Stilo AE0322? First you would have a Stilo Formula or Naked Helmet (no side ports), have a race car wired with NASCAR communications and want the Stilo noise reduction ear cup communication. Some formula cars with the engine close to the driver or a ultra high compression race V8. If your car is very loud, or you went to too many Who concerts when you were younger, this is a great communication upgrade.
Helmet connection: This Stilo cable uses a NASCAR (3C) male plug attached to a coil cord to ensure there are no accidental disconnects.
Audio In: This Stilo Ear Cup Electronics with Flex Mic and NASCAR Coil Cord uses the proven Stilo earcup audio electronics to keep the race car out and the crew member in your ear. There is also a 3.5mm female jack for earbuds. The receiving audio will work through the ear cups or earbuds or both together. This is a proven race worth set-up.
Microphone: Your Stilo helmet has a female recess in the front chin bar to to place a noise canceling microphone, but the 0231 kit uses a Gentex noise canceling microphone on the end of a flex-boom so you can place the microphone so it is barely touching you upper lip. This is popular in hi-speed formula cars, and extreme environments like Baja 1000, power boats, V8 SuperCars etc.
Stilo SRO-9217 Kit Details:
- Manufacturer: Stilo
- Manufacturer part number: SRO-9217-KIT
- Helmet Connection 1: Female IMSA connection to connect to the radio harness
- Helmet Connection 2: Female 3.5mm connection to connect to earbuds
- Microphone: Gentex noise canceling with flex boom
- Earpad kit: 2 soft noise transparent earpads
If you run in the SRO GT World Series, GT America, GT4 or TC America series, the SRO 2022 rule book removed the legal use of your Stilo earcup communication kit. Our Stilo SRO-9217 kit makes converting your Stilo GT series helmet to the SRO rules fast and easy. We include a genuine Stilo Gentex Boom Mic w/ 3.5mm Earbud Connection and SRO legal ear pad kit.
While Stilo earcup communications are still allowed in IMSA, NASCAR, INDYCAR, F4, F3 and many other series, you will need to convert your Stilo GT series helmet to compete while driving in the SRO series. The Stilo SRO-9217 helmet electronic kit replaces your Stilo earcup kit with a Gentex flex boom microphone, 3.5mm earbud connection and soft earpads.
Stilo AE0217 Kit Details:
- Manufacturer: Stilo
- Manufacturer part number: AE0217
- Helmet Connection 1: Female IMSA connection to connect to the radio harness
- Helmet Connection 2: Female 3.5mm connection to connect to earbuds
- Microphone: Gentex noise cancelling with flex boom
Stilo AE0217 is the helmet electronic kit that uses the female threaded receptacle, a Gentex flex boom microphone, and a 3.5mm earbud connection. If you are using your normal foam or custom earbuds and want a Gentex noise canceling microphone on a flex boom, this is your Stilo helmet wiring kit.
