AiM Sports GPS09C Module The GPS09C module from AiM further expands the track mapping abilities of AiM data loggers and dash loggers. In addition, the GPS09C allows lap timing (even split times) without the use of trackside beacons, storing data for as many as 50 race tracks and up to five splits per track. The GPS09C can also calculate and log speed, lateral and longitudinal g-forces, and of course vehicle position. The AiM GPS09CC is the basis of lap time and split time calculations in all AiM systems. These systems come with start/finish line coordinates for more than four thousand race tracks, so your dash or logger automatically recognizes the track you are racing on and will calculate lap times and split times. If the track you're on is not in the database, your system will recognizes a new track and then will calculate lap times. High 25 Hz Sampling and Exceptional Accuracy The GPS09C is the latest version, boasting a quicker 25 Hz sampling rate (up from 10 Hz) and positional accuracy to less than one foot (down from over six feet). It also takes full advantage of Race Studio 3 integration of GPS, video, and data. Simple to install: Just connect the CAN cable to your dash and mount the AiM GPS09C antenna to your vehicle. The Standard Version is magnetic-backed and can be installed inside the cabin or on the vehicle exterior. The Roof Version is designed to run the cable through an exterior panel for a clean, secure, more permanent installation. The GPS09C will automatically configure itself during start-up! The AiM GPS09C connects via a 5-pin Binder 712 screw-in connector. Choose a cable length to suit your installation: 0.5m (1.6 ft), 1.3m (4.3 ft) is appropriate for most formula cars and motorcycles; 2.0m (6.6ft) and 4.0m (13.1 ft) are suitable for most sports cars and sedans. AiM GPS09C Module Compatibility MX Series: MXS, MXP, MXG, MXT SmartyCam Series1: Sport, Corsa, GP, Dual Loggers:1: Evo S, Evo 5 Lap Timer: Solo2 DL Power Distribution Modules: PDM32, PDM08 1 not compatible with Pro and Pro Open versions

AiM Sports Pressure Sensor NOTE: Sensors typically take 3 to 5 business days to ship. Add the appropriate AiM Sports Pressure Sensor to your AiM data set-up to retrieve exactly the information you need to maximize your data acquisition and take your racing to the next level! All sensors have a 40 cm (16 inch) cable length

AiM Kart Racing Steering Angle Sensor Measure and log your kart driver's steering input with the AiM Steering Angle Sensor. Includes a rotary potentiometer with a male 4-pin 719-style connector, two toothed pulleys, one toothed belt, and one sensor mounting bracket. The steering shaft pulley is designed to fit a 7/8"-diameter shaft. (Smaller shafts will need to add a bushing to fit the pulley.) This sensor is designed to measure up to five complete turns of the steering column. This sensor requires the addition of an Expansion Box or eBox when used with MyChron3 Extreme, MyChron4, and MyChron5 kart dash loggers. If your steering column is larger than 7/8", consider using the AiM String Pot Steering Angle Sensor (Part No. AIM-MC-280) instead. The String Pot can work with any diameter steering shaft.

AiM Low Pressure Sensor 0-15 psi 1/8NPT This sensor has a 4-pin 719 (plastic push-on) connector and a male 1/8 NPT thread. AiM 1/8 NPT 0-15 psi Pressure Sensor is ideal for Coolant Pressure or low boost sensing measuring. When installed in the coolant system, you can sense a reduced coolant system pressure (leak) before your coolant is exhausted and engine is overheated. AiM 1/8 NPT Automotive Oil Pressure Sensor for Measuring 0 to 15psi for AiM MyChron, MXG, MXS, MXM, MXL2, MXL, EVO3, and EVO4 automotive applications. 1/8 NPT male threads direct into the block. AiM 0-15 psi Low Pressure Sensor 1/8 NPT Details: Manufacturer: AiM Manufacturer part number: X05PSA00015P18 Manufacturer alternate part number: PRS-832 1/8 NPT Alternate part number: MC-3XX 1/8NPT End 1: 719 4 Pin Push-On Male End 2: 1/8" NPT

AiM Brake Pedal Position Sensor, Linear Travel Pot (Auto) The AiM linear short stroke (10mm) displacement potentiometer is most popular ideal for measuring brake pedal movement. A pedal travel sensor such as this can be simpler to install in many vehicles than plumbing a pressure sensor in the brake line. Normally mounted in front of the brake pedal (between the driver and the pedal) so the sensor is depressed when the brakes are off. This will reduce the likelihood of sensor damage or interference with pedal travel in the event of brake fade. The sensor should be mounted close to the pedal pivot, and at an angle that minimizes side loading on the plunger. The compact sensor body measures just 3/4" (19mm) OD x 1 3/8" (35mm) long overall (less plunger). Two 1/4" (6mm) mounting holes are located 1.34" (34mm) center-to-center. This sensor has a 200mm (7 3/4") long cable with the 719 (four-pin plastic push-on type) connector. Use a My Chron 719-719 Patch Cable (Part No. MC-211) to connect to an AiM MXL Pista, MXL Pro, MXL2, MXG, MXS, or MyChron3 Auto dash (except XG-Log). XG-Log and EVO4 require a 712-719 Patch Cable (Part No. MC-210) for connection. AiM Brake Pedal Position Sensor, Linear Travel Pot (Auto) Details: Manufacturer: AiM Manufacturer part number: X05SNLPRSO Alternate part number: AIM-MC-321 Range: 10mm (.375 Inch) Electrical Connection Type: 719 (4 pin push-on style) Mounting eyelet: 6mm (1/4") on 34mm (1.34") bolt centers

AiM Steering Angle Sensor, Belt Type (Auto) The steering shaft pulley is designed to fit a 7/8" diameter shaft. Smaller shafts will need to add a bushing to fit the pulley. This sensor is designed to measure up to 5 complete turns of the steering column. This sensor can connect directly to the AiM MXL Pista / Pro dash, MXL2 / MXG / MXS dashes, or the EVO3 series data loggers. The MyChron3 XG-Log and the EVO4 logger both require a 712-719 Patch Cable (Part No. MC-210).We also offer the Replacement AiM Steering Angle Sensor Belt (Part No. MC-336) separately. DiscoveryParts Pro Tip: When mounting the sensor, locate the mount a little farther away than you might expect and use shims to bring the supplied bracket closer. If the belt tension is too loose, remove a shim or two to adjust. If your steering column is larger than 7/8", consider using the AiM String Pot Steering Angle Sensor (Part No. LX-PA-10-AIMSP) instead. The String Pot can work with any diameter steering shaft.

AiM Sports Position Sensors NOTE: Sensors typically take 3 to 5 business days to ship. Add the appropriate AiM Sports Position Sensor to your AiM data set-up to retrieve exactly the information you need to maximize your data acquisition and take your racing to the next level! All sensors have a 30cm (12 inch) cable length

AiM Magnetic Pedal Position Sensor For MyChron5 The accelerator/brake pedal position sensors is a crucial support device for kart drivers. They provide a precise indication of timing and intensity of braking and/or acceleration. This permits the team to understand whether the driver has accelerated or braked at the right moment, with the correct pedal strength, across multiple laps and overlaid with other critical data. This is a very important factor in evaluating driver behavior and improving his/her performance. Data can be acquired by your MyChron5 connected to a MyChron Expansion and analyzed on your PC. Made in anodized aluminium, these sensors are very robust and water-resistant. Calibration is immediate: once installed, connect the sensors to your MyChron Expansion and get pedal positions (in high position and zero position). After that the sensor will start getting acceleration or braking data. Call us with any questions you have about the incredible new MyChron5 2T from AiM!

AiM Magnetic Wheel Speed Sensor - 719 Lead This sensor has the 719 (four-pin plastic push-on type) connector to connect to the MyChron3 Plus or Gold Auto dashes, any AiM MXL series dash, or any EVO3 series data logger. The MyChron3 XG-Log requires a 712-719 Patch Cable (Part No. MC-210). The EVO4 requires either the MC-210 patch cable or the Y-Cable for Dual Speed Sensors (Part No. MC-264). The front of the sensor has M8 threads for easy mounting in a bracket you supply. We also offer Replacement Speed Sensor Magnets for installation on a spare wheel, or for adding multiple trigger points. Tip: Add a longer 719-719 Extension Cable (Part No. MC-211, sold separately) and install your wheel speed sensor with the plug near the suspension pick-up point. In the event of crash damage, the sensor will be much easier to replace without fishing a new lead through the car.

AiM Sports EGT Thermocouple Sensors Add the appropriate AiM Sports Exhaust Gas Temperature sensor to your AiM data set-up to retrieve exactly the information you need to maximize your data acquisition and take your racing to the next level! AiM devices can measure exhaust gas temperature using a sensor – thermocouple – placed in the exhaust header pipe. All AiM thermocouples are K-type sensors and fit car, motorcycle, and karting installations. Cable length is 250mm (~10 in.) TEMPERATURE SENSOR TYPES K-type thermocouple, M5 thread (includes weld nut) K-type thermocouple, T12 (CIK-FIA homologated)

AiM MyChron4/5/5S 2T Y-Cable This AiM Sports Y-Cable is designed for the MyChron5 and MyChron 5S 2T kart dashes with two temperature control capabilities. One end of the AiM Y-Cable has one Binder 712 seven-pin male (screw-in) terminal to connect to your MyChron dash. The other end has one K-type (two-pin flat yellow) female connector to accept a K-type thermocouple, and one Binder 712 four-pin female (push-in) connector for a thermoresistor temperature sensor. AiM MYCHRON4/5/5S Y-CABLE DETAILS Manufacturer: AiM Sports Manufacturer part no: V02557110 Karting only: yes MyChron end: 7-pin Binder 712 male (screw-in) Sensor end 1: 4-pin Binder 712 female (push-in) Sensor end 2: K-Type 2 pin flat yellow female

MyChron5 & 4 2T Y-Cable, CHT & EGT - 5 meter One of the most common uses of this cable is to use an under the spark plug cylinder head temperature (CHT) and an exhaust gas temperature (EGT). We use this on a Yamaha KT100, LO206, Animal or clone motor to record both CHT & EGT as our two temperature inputs. AiM Y-Cable is designed for the MyChron5 2T kart dash.This Y-Cable is designed for the MyChron5 2T and MyChron4 2T kart dash. It has a 712 7-pin male connector for the dash, and two K-type (2-pin flat yellow) female connectors to accept K-type thermocouples. Manufacturer: AiM Kart Only: Yes MyChron5 2T: Yes MyChron4 2T: Yes Cable End 1: 7-pin 712 screw on (dash) Cable End 2: K-Type (2 pin flat yellow female - egt or CHT) Cable End 3: K-Type (2 pin flat yellow female - egt or CHT) DiscoveryParts part number: V025571105M

MyChron5 & 4 2T Y-Cable, CHT & EGT One of the most common uses of this cable is to use an under the spark plug cylinder head temperature (CHT) and an exhaust gas temperature (EGT). We use this on a Yamaha KT100, LO206, Animal or clone motor to record both CHT & EGT as our two temperature inputs. MyChron 5 & 4 2T Y-Cable, CHT & EGT Details: Manufacturer: AiM Manufacturer part number: V02557070 Alternate part number: MC-016 Kart Only: Yes MyChron5 2T: Yes MyChron4 2T: Yes Cable End 1: 7-pin 712 screw on (dash) Cable End 2: K-Type (2 pin flat yellow female - egt or CHT) Cable End 3: K-Type (2 pin flat yellow female - egt or CHT) Length of 712 7 pin male to cunction: 54.5" Lengh of junction to flat yellow egt or CHT coupler: 2.5" AiM Y-Cable is designed for the MyChron5 2T kart dash. This Y-Cable is designed for the MyChron5 2T and MyChron4 2T kart dash. It has a 712 7-pin male connector for the dash, and two K-type (2-pin flat yellow) female connectors to accept K-type thermocouples.

AiM Sports CHT Thermocouple Sensors Add the appropriate AiM Sports Cylinder Head Temperature sensor to your AiM data set-up to retrieve exactly the information you need to maximize your data acquisition and take your racing to the next level! AiM devices can measure the cylinder head temperature using a sensor – thermocouple – placed between the spark plug and the cylinder head. All AiM thermocouples are K-type sensors. Install this CHT thermocouple to monitor temperatures ranging from 0º to 572ºF (up to 300ºC). Choose your sensor diameter to fit either 14mm, 12mm, or 10mm spark plugs. The sensing ring is 0.7 inch (18mm) thick. TEMPERATURE SENSOR CHOICES This thermocouple is available to fit three different spark plug diameters, various cable lengths, and two different end connectors as follows: CHT14B: 14mm diam, 1.5m cable length, Binder 712 3-pin male   CHT14M: 14mm diam, 0.4m cable length, Mignon 2-pin male CHT12B: 12mm diam, 1.4m cable length, Binder 712 3-pin male CHT12M: 12mm diam, 0.4m cable length, Mignon 2-pin male CHT10B: 10mm diam, 1.4m cable length, Binder 712 3-pin male CHT10M: 10mm diam, 0.4m cable length, Mignon 2-pin male
